Fluke 750PA9
Roll over image to zoom in
$1,290.00
Fluke 750PA9 Absolute Pressure Module delivers precise pressure measurements up to 1500 psia (100 bar, 10 MPa) with 0.025% reference uncertainty, designed for Fluke multifunction and documenting process calibrators. Ideal for professional calibration applications in industrial environments.
Fluke 750PA9 – Absolute Pressure Module, 0 – 1500 psia (0 – 100 BAR), (0 – 10 MPA).
The Fluke 750PA9 Absolute Pressure Module is engineered for high-accuracy absolute pressure measurements in demanding calibration environments. Designed for seamless integration with Pressure Calibrators such as the Fluke 750 Series, 740 Series, and 725/726 multifunction calibrators, this module ensures fast, precise, and reliable readings with minimal setup.
With a reference uncertainty of just 0.025% and full temperature compensation from 0°C to 50°C, the Fluke 750PA9 guarantees dependable performance across a variety of industrial applications, including plant maintenance, process control, and laboratory calibration. Its digital communication system eliminates analog signal errors, while the interchangeable design allows quick swapping between calibrators without compromising accuracy.
Whether you are testing industrial pressure transmitters or verifying process instrumentation, the 750PA9 simplifies the workflow—just connect to a pressure source, link to your calibrator, and view results instantly in up to 11 engineering units. For a broader look at compatible tools, explore our Calibration Instrument Collection .
Key Features
-
Pressure Range: 0–1500 psia (0–100 bar / 0–10 MPa)
-
Reference Uncertainty: 0.025% (±0.03%)
-
Temperature Compensation: 0°C to 50°C
-
Digital Communication: Prevents analog signal loss
-
Interchangeable Calibration Module: Maintains accuracy when swapped
-
Wide Unit Selection: Displays results in 11 engineering units
-
Pressure Connection: 1/8″ NPT female with adapters for 1/4″ NPT, 1/4″ BSP, and M20 male threads
-
Media Compatibility: Stainless steel 316-SS
-
Burst Rating: 3x max pressure
-
Durability: Urethane molded cover for shock, dust, and moisture resistance
Included Accessories
-
(1) 1/8″ NPT Male-to-1/4″ NPT Male Adapter
-
(1) 1/8″ NPT Male-to-1/4″ BSP Male Adapter
-
(1) 1/8″ NPT Male-to-M20 Male Adapter
-
(1) O-Ring (-111) Cast Urethane
-
(1) Certificate of Calibration
-
(1) User Manual
Technical Specifications
| Parameter | Value |
|---|---|
| Pressure Range | 0–1500 psia (0–100 bar, 0–10 MPa) |
| Reference Uncertainty | 0.025% / ±0.03% |
| Temperature Compensation | 0°C to 50°C |
| Pressure Port Type | Absolute |
| Burst Rating | 3x max pressure |
| Media Compatibility | Stainless steel 316-SS |
| Digital Communication | Yes |
| Adapters Included | NPT, BSP, M20 |
| Calibration Included | NIST Traceable |
| Warranty | 1 Year |
