Keysight N6782A: Precision Source Measure Unit for Functional Testing

Keysight N6782A – Two Quadrant SMU Module for Functional Tests (20W).

The Keysight N6782A Two-Quadrant Source/Measure Unit (SMU) is engineered to provide exceptional precision and versatility for functional testing of electronic devices, including DC/DC converters, power management units, power amplifiers, and embedded system circuits. Designed for seamless integration with the Keysight N6700 Low-Profile Modular Power System or the N6705 DC Power Analyzer, this single-slot 20 W module supports both source and sink (2-quadrant) operation, allowing complete control over device input and output behavior.

Delivering up to 20 V or ±3 A, the N6782A offers high-speed modulation up to 100 kHz, fast transient response, and low noise performance. Its advanced source and measurement capabilities enable engineers to simulate real-world power conditions, characterize DUT behavior, and validate energy efficiency in R&D and automated test environments.

With its integrated measurement accuracy, programmable ranges, and wide dynamic response, the N6782A ensures consistent performance across a variety of applications where precision power sourcing and load emulation are critical.

For more advanced modules and configurations, explore related products in the Keysight SMU series:

• N6781A – Battery Drain Analysis SMU

• N6784A – 4-Quadrant General Purpose SMU

Or visit category pages for:

• Source Measure Units (SMU)

• Power Supplies

• Power Analyzers

Key Features

• Two-quadrant (source and sink) operation for functional testing

• Output power up to 20 W

• Voltage range: Up to 20 V

• Current range: Up to ±3 A

• High-speed modulation up to 100 kHz

• Fast transient response for realistic DUT simulation

• Seamless integration with Keysight N6700 and N6705 systems

• Compact single-slot module for space-efficient test setups

• Ideal for power ICs, converters, and embedded systems testing

Technical Specifications
