Teledyne LeCroy T3CP150-12: Precision Current Probe for AC/DC Measurements
Roll over image to zoom in
$2,370.00
Teledyne LeCroy T3CP150-12 high-performance AC/DC current probe with 12 MHz bandwidth and 150 A RMS capacity. Designed for accurate waveform analysis in power electronics, EV drives, and inverter testing with ±1% measurement precision.
Teledyne LeCroy T3CP150-12 T3CP AC/DC Current Probe for the Oscilloscopes, 150 A, 12 MHz.
The Teledyne LeCroy T3CP150-12 is a versatile AC/DC current probe designed for use with any oscilloscope featuring a high-impedance BNC input. It delivers accurate waveform capture with up to 1% measurement accuracy, low insertion loss, and wide bandwidth (DC to 12 MHz)—making it ideal for design, testing, and troubleshooting of switching power supplies, motor drives, electric vehicles, and UPS systems.
Powered by an external universal power supply, the probe supports both DC and AC measurements with dual sensitivity ranges (30 A and 150 A) and automatic zero/degauss functions for maximum accuracy. The over-current protection and dual LED indicators enhance operational safety during measurements.
Applications
-
Switching and linear power design
-
Electric vehicle motor and drive testing
-
Power train and inverter development
-
Consumer and industrial electronics
-
Photovoltaic (PV) system design
-
LED lighting power systems
-
Educational and R&D laboratories
If you’re comparing current probes and oscilloscope accessories, explore related high-performance models available at Matson Calibration:
These models provide similar functionality and are ideal for oscilloscope-based current measurements across various frequency and current ranges.
Technical Specifications
| Parameter | Specification |
|---|---|
| Bandwidth (-3 dB) | DC to 12 MHz |
| Continuous Maximum Input | 150 A RMS |
| Maximum Peak Input | 300 A (≤10 µs) |
| Current Ranges | 30 A / 150 A |
| Current Transfer Ratio | 30 A: 1 V/A, 150 A: 0.01 V/A |
| Minimum Measurable Current | 30 A: 5 mA, 150 A: 50 mA |
| Amplitude Accuracy | ±1% |
| Max Conductor Diameter | 5 mm |
| Power Supply | DC 12 V / 1 A (included) |
| Dimensions | 176 × 39.5 × 18 mm |
| Weight | 235 g |
Included Items
-
Teledyne LeCroy T3CP150-12 AC/DC Current Probe
-
Calibration Report
-
Universal Power Supply
-
BNC Cable
-
Instruction Manual
-
One-Year Warranty
Additional information
| Brand | Teledyne LeCroy |
|---|
