Teledyne LeCroy T3VNA3200: Advanced Vector Network Analyzer for Precise RF Measurements
Roll over image to zoom in
$5,945.00
The Teledyne LeCroy T3VNA3200 is a high-performance Vector Network Analyzer (VNA) designed for precise S-parameter, frequency, and impedance measurements up to 3.2 GHz. Combining VNA, Spectrum Analyzer, and Distance-To-Fault (DTF) capabilities, it provides powerful multi-function analysis in a single compact benchtop instrument.
Teledyne LeCroy T3VNA3200 – Vector Network Analyzer (9 kHz to 3.2 GHz).
Product Overview
The Teledyne Test Tools T3VNA3200 is a versatile 2-port Vector Network Analyzer that integrates multiple RF test capabilities in one platform. Covering a wide frequency range from 9 kHz to 3.2 GHz, it enables engineers to characterize components, cables, and antennas with high accuracy.
Its built-in Spectrum Analyzer and Distance-To-Fault (DTF) mode enhance diagnostic flexibility, while the Advanced Measurement Kit supports complex RF performance tests such as CHP, ACPR, OBW, CNR, and TOI. The intuitive 10.1-inch color WVGA touchscreen display ensures smooth operation and rapid data interpretation.
Designed for both laboratory and field testing, the T3VNA3200 combines portability, accuracy, and rich measurement functionality—ideal for RF design validation, production testing, and educational research.
Key Features
-
Frequency Range: 9 kHz to 3.2 GHz
-
2-Port Vector Network Analyzer with full S-parameter measurement capability
-
Integrated Spectrum Analyzer and DTF modes for comprehensive RF testing
-
Advanced Measurement Kit: CHP, ACPR, OBW, CNR, TOI, and more
-
Built-in switchable pre-amplifier for improved signal sensitivity
-
10.1” WVGA (1024 × 600) color touchscreen for clear data visualization
-
Compact benchtop design with USB and LAN interfaces
-
Includes Utility and Calibration Kits as standard
-
Ideal for: Antenna characterization, RF filter tuning, impedance matching, and network component analysis
Technical Specifications
| Specification | Description |
|---|---|
| Brand | Teledyne LeCroy |
| Model | T3VNA3200 |
| Frequency Range | 9 kHz – 3.2 GHz |
| Spectrum Analysis Range | 9 kHz – 3.2 GHz |
| Number of Ports | 2 |
| Display | 10.1” WVGA touchscreen |
| Type | Benchtop |
| Series | T3VNA Series |
| Pre-Amplifier | Built-in (switchable) |
| Measurement Modes | VNA, Spectrum, DTF |
| Calibration | Utility and Calibration Kits included |
Applications
-
RF component and antenna testing
-
Cable and connector analysis
-
S-parameter characterization
-
Network impedance and return loss measurements
-
Wireless communication system verification
